Part Number: 13796
Description Part Number: VL1-24PS45-FCCT-H
0-10V/Dimmable
Selectable Wattage - 45/35/26w
Voltage - 120-347v
Selectable CCT - 35/40/50K
Lumens - 6,300/4,900/3,640lm
Equivalent - 2 x 32WT8, 3 x 32WT8 Fluorescent
Avg. Rated Life (L70) - 100,000 Hrs.
Finish - White/Frosted
Height - 2.1" (54mm)
Length - 47.8" (123mm)
Width - 23.7" (603mm)
- Controls Ready Architectural recessed retrofit luminaire, Controls Ready makes adding controls quick and easy, Includes snap-in receptacle for Standalone and Networked Lighting Controls
- Flat modern lens featuring high-quality, IK07 Rated non-yellowing PMMA acrylic lens ensures optimal light uniformity
- Multiple mounting options: recessed, suspended, surface mount
- 0-10V Dimming, dim-to-off, Surge Protection: 2.5kV, White powder coated steel housing
- UL Listed, DLC Listed, Damp Location Rated, RoHS Compliant, FCC Compliant, ICES-005 Compliant, IC Rated for insulation contact
- 5 year limited factory warranty
-
-
-
-
-
- Tech Specs
-
| -
-
-
|
-
-
-
| -
-
| -
-
-
- Voltage Rating
-
| -
- 120-347V
| -
-
-
| Equivalent | -
2 x 32WT8, 3 x 32T8 Fluorescent
| -
-
-
| Selectable Wattage | -
| 45 Watts/35 Watts/26 Watts | -
-
-
| Dimmable | -
| YES/0-10V | -
-
-
| Lumens | -
| 6,300LM/4,900LM/3,640LM | -
-
-
| Selectable CCT | -
| 3500K/4000K/5000K | -
-
-
- CRI
| -
>80
| -
-
-
| Warranty | -
| 5 Year Limited Factory Warranty | -
-
-
| Lumens Per Watt | 140 LM/W | -
-
-
| Avg. Rated Life (L70) | -
| 100,000 Hours | -
-
-
| Fixture Size | -
| 2' X 4' | -
-
-
-
|
|
|
|
